Name: GTS_Aquifers

Display Field: GTS_AQUIFER_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>The North Dakota Geographic Targeting System for Groundwater Monitoring (GTS) was first conducted in 1997 as a method of assigning monitoring priority to shallow aquifers. The decision to update the monitoring priority was made in 2015 in response to changing aquifer boundaries, land use, and groundwater appropriation. The analysis was complete and first published in 2018. Additional update to address water levels in confined aquifers was published in October 2019. </SPAN><SPAN>In January 2021, 68 new aquifers were added to the layer that were included in the "2021 Addendum to the 2019 North Dakota Geographic Targeting System For Groundwater Monitoring". Four aquifer names were also updated and all aquifer boundaries were updated to match North Dakota State Water Commission aquifer delineations and names as of January 2021. The January 2021 addendum report is available online at </SPAN><A href="https://deq.nd.gov/publications/wq/1_GW/GeoTargetSys/2021_GTS_Addendum.pdf"><SPAN>https://deq.nd.gov/publications/wq/1_GW/GeoTargetSys/2021_GTS_Addendum.pdf</SPAN></A><SPAN>; The completed 2019 report is available online at </SPAN><A href="https://deq.nd.gov/publications/wq/1_GW/GeoTargetSys/2018_GTS/2019_GTS_Report_October2019.pdf"><SPAN>https://deq.nd.gov/publications/wq/1_GW/GeoTargetSys/2018_GTS/2019_GTS_Report_October2019.pdf</SPAN></A></P><P><SPAN>The GTS consists of three components: Vulnerability, Sensitivity, and Risk. Each component is given three values: a Value, a Score, and a Rating. The Value is the numeric representation of each component. The Score is a number ranging from 1 to 3, and is assigned based on the Value range. A Rating can be LOW, MODERATE, or HIGH, and correlates to a Score rating of 1, 2, or 3 respectively. </SPAN></P><P><SPAN><SPAN>The score of each component is added together to achieve a total monitoring score ranging from 3 - 9. The Total Monitoring Rating is then assigned based on this score: 3-4 (LOW), 5-7 (MODERATE), 8-9 (HIGH). </SPAN></SPAN></P><P><SPAN><SPAN>This dataset has value, score, and rating fields for each component, total monitoring score, total monitoring rating, and DRASTIC and Pesticide DRASTIC value fields. </SPAN></SPAN></P><P><SPAN><SPAN>COMPONENT RATINGS</SPAN></SPAN></P><P><SPAN><SPAN>Vulnerability</SPAN></SPAN></P><P><SPAN><SPAN>Pesticide DRASTIC Value - Score - Rating</SPAN></SPAN></P><P><SPAN><SPAN>0-129 - 1 - LOW</SPAN></SPAN></P><P><SPAN>130-159 - 2 - MODERATE</SPAN></P><P><SPAN><SPAN>160+ - 3 - HIGH</SPAN></SPAN></P><P><SPAN><SPAN>Sensitivity</SPAN></SPAN></P><P><SPAN><SPAN>Production (in dollars per farmed acre) Value - Score - Rating</SPAN></SPAN></P><P><SPAN><SPAN>0-202.14 - 1 - LOW</SPAN></SPAN></P><P><SPAN><SPAN>202.15 - 356.91 - 2 - MODERATE</SPAN></SPAN></P><P><SPAN><SPAN>356.92+ - 3 - HIGH</SPAN></SPAN></P><P><SPAN><SPAN>Risk</SPAN></SPAN></P><P><SPAN><SPAN>Appropriated acre-feet per square mile - Score - Rating</SPAN></SPAN></P><P><SPAN><SPAN>0-1.243 - 1 - LOW</SPAN></SPAN></P><P><SPAN>1.244-33.51 - 2 - MODERATE</SPAN></P><P><SPAN><SPAN>33.52+ - 3 - HIGH</SPAN></SPAN></P><P><SPAN><SPAN>Total Monitoring Score</SPAN></SPAN></P><P><SPAN><SPAN>Vulnerability Score + Sensitivity Score + Risk Score = Monitoring Score (Monitoring Rating)</SPAN></SPAN></P><P><SPAN><SPAN>3-4 (LOW)</SPAN></SPAN></P><P><SPAN><SPAN>5-7 (MODERATE)</SPAN></SPAN></P><P><SPAN><SPAN>8-9 (HIGH)</SPAN></SPAN></P><P><SPAN>Dataset Finalized: January 2021</SPAN></P></DIV></DIV></DIV>

Copyright Text: 2012 Census of Agriculture/ U.S. Department of Agriculture. USDA Census of Agriculture. N.p., n.d. Web. 15 June 2016. Linda Aller, Truman Bennett, Jay H. Lehr, and Rebecca J. Petty. DRASTIC: A Standardized System for Evaluating Ground Water Pollution Potential Using Hydrogeologic Settings. Chicago: U.S. Environmental Protection Agency, 1985. Print. North Dakota State Water Commission Scott Radig. North Dakota Geographic Targeting System for Groundwater Monitoring.Bismarck: U.S. North Dakota Department of Health, 1997. Print. Authors: Budde, Nick; Kannenberg, Derek; Peterson, Andrew; Gleich, Casey; North Dakota Department of Environmental Quality - Division of Water Quality, Groundwater Protection Program.

Default Visibility: false

MaxRecordCount: 1000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.1582671110376867E7
YMin: 5752963.015740613
XMax: -1.075026030609656E7
YMax: 6274810.471639203
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: GTS_TM_RATING
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: LOW
  Label: LOW
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [255, 198, 62, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Value: MODERATE
  Label: MODERATE
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [255, 127, 72, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
• Value: HIGH
  Label: HIGH
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [255, 0, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [110, 110, 110, 255]
  Width: 0
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• GTS_AQUIFER_NAME ( type: esriFieldTypeString, alias: GTS_AQUIFER_NAME, length: 255 )
• GTS_DRASTIC ( type: esriFieldTypeInteger, alias: GTS_DRASTIC )
• GTS_PESTICIDE_DRASTIC ( type: esriFieldTypeInteger, alias: GTS_PESTICIDE_DRASTIC )
• GTS_VULNERABILITY_SCORE ( type: esriFieldTypeInteger, alias: GTS_VULNERABILITY_SCORE )
• GTS_VULNERABILITY_RATING ( type: esriFieldTypeString, alias: GTS_VULNERABILITY_RATING, length: 255 )
• GTS_CHEM_USE_SENSITIVITY ( type: esriFieldTypeDouble, alias: GTS_CHEM_USE_SENSITIVITY )
• GTS_SENSITIVITY_SCORE ( type: esriFieldTypeInteger, alias: GTS_SENSITIVITY_SCORE )
• GTS_SENSITIVITY_RATING ( type: esriFieldTypeString, alias: GTS_SENSITIVITY_RATING, length: 255 )
• GTS_USE ( type: esriFieldTypeDouble, alias: GTS_USE )
• GTS_RISK_SCORE ( type: esriFieldTypeInteger, alias: GTS_RISK_SCORE )
• GTS_RISK_RATING ( type: esriFieldTypeString, alias: GTS_RISK_RATING, length: 255 )
• GTS_TM_SCORE ( type: esriFieldTypeInteger, alias: GTS_TM_SCORE )
• GTS_TM_RATING ( type: esriFieldTypeString, alias: GTS_TM_RATING, length: 255 )
• the_geom_Length ( type: esriFieldTypeDouble, alias: the_geom_Length )
• the_geom_Area ( type: esriFieldTypeDouble, alias: the_geom_Area )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
