Parent Layer: Statewide

Name: Contours 24k

Display Field: PERMANENT_IDENTIFIER

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>These vector contour lines are derived from the 3D Elevation Program using automated and semi-automated processes. They were created to support 1:24,000-scale CONUS and Hawaii, 1:25,000-scale Alaska, and 1:20,000-scale Puerto Rico / US Virgin Island topographic map products, but are also published in this GIS vector format. Contour intervals are assigned by 7.5-minute quadrangle, so this vector dataset is not visually seamless across quadrangle boundaries. The vector lines have elevation attributes (in feet above mean sea level on NAVD88), but this dataset does not carry line symbols or annotation.</SPAN></P></DIV></DIV></DIV>

Copyright Text: U.S. Geological Survey

Default Visibility: false

MaxRecordCount: 1000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 25000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: false

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.159115058158162E7
YMin: 5760341.627511624
XMax: -1.0746208872577237E7
YMax: 6275095.335905715
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: FCODE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: 10101
  Label: Normal Intermediate
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [219, 165, 64, 255]
  Width: 0
• Value: 10102
  Label: Normal Index
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [163, 119, 23, 255]
  Width: 1
• Value: 10104
  Label: Depression Intermediate
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [219, 165, 64, 255]
  Width: 0
• Value: 10105
  Label: Depression Index
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [163, 119, 23, 255]
  Width: 1
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• PERMANENT_IDENTIFIER ( type: esriFieldTypeString, alias: Permanent_Identifier, length: 40 )
• SOURCE_FEATUREID ( type: esriFieldTypeString, alias: Source_FeatureID, length: 40 )
• SOURCE_DATASETID ( type: esriFieldTypeString, alias: Source_DatasetID, length: 40 )
• SOURCE_DATADESC ( type: esriFieldTypeString, alias: Source_DataDesc, length: 100 )
• SOURCE_ORIGINATOR ( type: esriFieldTypeString, alias: Source_Originator, length: 130 )
• LOADDATE ( type: esriFieldTypeDate, alias: LoadDate, length: 8 )
• FCODE ( type: esriFieldTypeInteger, alias: FCode , Coded Values: [10101: Normal Intermediate] , [10102: Normal Index] , [10103: Normal Supplemental] , ...18 more... )
• CONTOURELEVATION ( type: esriFieldTypeDouble, alias: ContourElevation )
• CONTOURUNITS ( type: esriFieldTypeInteger, alias: ContourUnits , Coded Values: [1: Feet] , [2: Meters] , [99: Unknown] )
• CONTOURINTERVAL ( type: esriFieldTypeDouble, alias: ContourInterval )
• NEDRESOLUTION ( type: esriFieldTypeDouble, alias: NEDResolution )
• CELL_ID ( type: esriFieldTypeInteger, alias: Cell_ID )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: globalid, length: 38 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
